Amphenol L17H Series, 15 Way Right Angle Through Hole Stacked PCB D-Sub Connector Plug, 2.77mm Pitch

Description

Series: L17H

Current Rating: 3.0A

Dimensions: 39.24 x 25.7 x 31.6mm

Mounting Type: Through Hole

Voltage Rating: 250.0 V

Gender: Male

Body Orientation: Right Angle

Termination Method: Solder

Length: 39.24mm

Housing Material: Steel

Width: 25.7mm

Depth: 31.6mm

Contact Plating: Gold over Nickel Pitch: 2.77mm Mounting Hardware: Boardlocks, 4-40 UNC Female Screwlocks Number of Contacts: 15 Maximum Operating Temperature: +125°C Minimum Operating Temperature: -55.0°C Contact Material: Brass

This is L17H Series 15 Way Right Angle Through Hole Stacked PCB D-Sub Connector Plug 2.77mm Pitch manufactured by Amphenol. The manufacturer part number is L17H2330131. The product l17h, is a highly preferred choice for users. The product has a current rating of 3.0a. The given dimensions of the product include 39.24 x 25.7 x 31.6mm. The product is available in through hole configuration. Moreover, the product has a nominal 250.0 v voltage rating. In addition, male is the available “Gender” of the product. It has right angle body orientation. It allows solder termination method. Its accurate length is 39.24mm. The product also features robust steel housing material. Furthermore, the product is 25.7mm wide. The product comes in 31.6mm depth. The high-quality gold over nickel is used as contact plating material. Moreover, the product is 2.77mm. It has boardlocks, 4-40 unc female screwlocks hardware mounting . The product contains 15 contacts. It has a maximum operating temperature of +125°c. Whereas, the minimum operating temperature of the product is -55.0°c. The product is made from sturdy brass materials.
