RE225-LF, Single Sided DIN 41652 Eurocard PCB FR4 with 35 x 42 1mm Holes, 2.54 x 2.54mm Pitch, 160 x 100 x 1.5mm

Description

Hole Layout: 35 x 42

Copper Thickness: 35µm

Dimensions: 160 x 100 x 1.5mm

Connection: DIN 41652

Hole Pitch: 2.54 x 2.54mm

Thickness: 1.5mm

Width: 100mm

Length: 160mm

FR Material Grade: FR4

Hole Diameter: 1mm

Base Material: Epoxy Glass Fabric Laminate

Number of Sides: 1

This is Single Sided DIN 41652 Eurocard PCB FR4 with 35 x 42 1mm Holes 2.54 x 2.54mm Pitch 160 x 100 x 1.5mm manufactured by Roth Elektronik. The manufacturer part number is RE225-LF. It has a 35 x 42 layout hole . Its copper thickness is about 35µm . The given dimensions of the product include 160 x 100 x 1.5mm. It has a standard din 41652 connection . Its hole pitch is about 2.54 x 2.54mm . It is 1.5mm thick. Furthermore, the product is 100mm wide. Its accurate length is 160mm. Moreover, its FR material is of fr4 grade . Has a hole diameter of 1mm. Its base is made up of epoxy glass fabric laminate material . Additionally, it is/has 1 sides .
