STMicroelectronics STEVAL-ESC001V1

Description

For Use With: L6398, STL160NS3LLH7, STM32F303

Kit Classification: Evaluation Board

Kit Name: STEVAL

HTSUS: 8537.10.9170

RoHS Status: Not applicable

Secondary Attributes: –

Type: Power Management

Function: Motor Controller/Driver

Primary Attributes: –

REACH Status: REACH Unaffected

Embedded: –

Package: Bulk

Moisture Sensitivity Level (MSL): 1 (Unlimited) standardLeadTime: 26 Weeks Utilized IC / Part: STM32F303, L6398, STL160NS3LLH7 Series: – Supplied Contents: Board(s) Base Product Number: STEVAL ECCN: 3A991A2

The STMicroelectronics STEVAL-ESC001V1 is a cutting-edge motor controller/driver power management evaluation board designed for high-performance motor control applications. This board integrates the STM32F303 microcontroller, the L6398 gate driver, and the STL160NS3LLH7 power MOSFETs to deliver exceptional motor control capabilities. Its integration of advanced components, robust communication interfaces, and comprehensive power management features make it a game-changer in the field of motor control technology.

Special Features and Benefits

• The STEVAL-ESC001V1 is powered by the STM32F303, an advanced 32-bit microcontroller.
• Its high processing power, floating-point unit, and extensive peripherals make it perfect for demanding motor control tasks.
• With the L6398 gate driver, this board provides precise and efficient control of the power MOSFETs.
• Equipped with UART and SPI interfaces, it seamlessly connects to external devices and enables real-time communication for system monitoring and control.
• These power MOSFETs offer low RDS(on) values, reducing power dissipation and enhancing overall system efficiency.

Comprehensive Power Management

The board features sophisticated power management capabilities, including overcurrent and overtemperature protection, ensuring the safety and durability of your motor system.

Application Versatility of the Evaluation Board

The STEVAL-ESC001V1 is a versatile power management evaluation board that empowers engineers to develop high-performance motor control solutions for various applications, including:

• The STEVAL-ESC001V1 is ideal for motor control in EVs and HEVs, ensuring efficient and precise control of traction motors and auxiliary systems.
• In industrial automation, it can control conveyor belts, robotic arms, and other machinery with precision, contributing to increased productivity and reduced downtime.
• For solar trackers and wind turbine pitch control, this board offers optimal motor control for tracking the sun and adjusting blade angles.
• From high-efficiency washing machines to smart kitchen appliances, this board enhances the performance and energy efficiency of various household devices.
• Medical devices like infusion pumps and respirators ensure precise and reliable motor control, which is critical for patient safety.
