TE Connectivity 10VW1 Powerline Filter, 10 A, 250 V ac

Description

Dimensions: 98 x 38.9 x 52.8mm

Mounting Type: Flange Mount

Series: Corcom W

Maximum Current Rating: 10A

Termination Style: Fast-On

Length: 98mm

Height: 52.8mm

Depth: 38.9mm

Minimum Operating Temperature: -10°C

Maximum Voltage Rating: 250 V ac

Operating Frequency: 50/60Hz

Number of Phases: 1

Maximum Operating Temperature: +40°C

This is Powerline Filter 10 A 250 V ac manufactured by TE Connectivity. The manufacturer part number is 10VW1. The given dimensions of the product include 98 x 38.9 x 52.8mm. The product is available in flange mount configuration. The product corcom w, is a highly preferred choice for users. Additionally, the product has a maximum 10a current rating . Moreover, it has fast-on terminal style. Its accurate length is 98mm. In addition, the height is 52.8mm. The product comes in 38.9mm depth. Whereas, the minimum operating temperature of the product is -10°c. It has a maximum 250 v ac voltage rating. Furthermore, the product has 50/60hz operating frequency range. Whereas it is comprised of 1 phases. It has a maximum operating temperature of +40°c.
