Vishay Aluminium Electrolytic Capacitor 5600μF 80V dc 36mm Snap-In 256 Series Aluminium, Through Hole Electrolytic

Description

Diameter: 36mm

Ripple Current: 3.39A

Dimensions: 36 (Dia.) x 47mm

Mounting Type: Snap-In

Series: 256

Equivalent Series Resistance: 59mΩ

Height: 47mm

Capacitance: 5600µF

Voltage: 80V dc

Leakage Current: 1.5 mA

Lifetime: 2000h

Lead Pitch: 10mm

Maximum Operating Temperature: +105°C Tolerance: ±20% Minimum Operating Temperature: -40°C Technology: Aluminium Electrolytic

This is Aluminium Electrolytic Capacitor 5600μF 80V dc 36mm Snap-In 256 Series Aluminium Through Hole Electrolytic manufactured by Vishay. The manufacturer part number is MAL225652562E3. Its diameter is 36mm. Furthermore, 3.39a is the ripple current. The given dimensions of the product include 36 (dia.) x 47mm. The product is available in snap-in configuration. The product 256, is a highly preferred choice for users. It has 59mω equivalent series resistance. In addition, the height is 47mm. It provides a 5600µf of capacitance value. It carries a 80v dc of voltage. It harbors 1.5 ma of leakage current. It provides a long-lasting service for a period of 2000h. The lead features 10mm pitch. It has a maximum operating temperature of +105°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -40°c. This product use aluminium electrolytic technology.
