Weidmuller 1469560000

Description

Number of Outputs: 1

Ripple And Noise: <50mV

Output Current: 40A

Standards Met: 61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61558-2-16, VDE 0100-410/DIN57100-410, VDE 0106-101

Mounting Type: DIN Rail Mount

Maximum Temperature: +70°C

Series: PRO ECO

Electrical Phase: 3

Special Features: Compact Size, Easy to Maintain, Flexible, High Efficiency

AC or DC Input Voltage: ac, dc

Height: 125mm

Width: 160mm

Depth: 100mm MTBF: >500000h Output Voltage: 24V dc Minimum Temperature: -25°C AC or DC Output Voltage: dc Power Rating: 960W Input Voltage: 320 → 575V ac Manufacturer Standard Lead Time: 16 Weeks Number of Outputs: 1 Detailed Description: Enclosed AC DC Converter 1 Output 24V 40A 320 ~ 575 VAC, 450 ~ 800 VDC Input Voltage – Isolation: 3kV Features: Adjustable Output, IP20 Mounting Type: DIN Rail Applications: Industrial, ITE (Commercial) Series: PRO ECO3 (960W) Voltage – Output 1: 24V Size / Dimension: 6.30″ L x 4.72″ W x 4.92″ H (160.0mm x 120.0mm x 125.0mm) Efficiency: 90% Power (Watts): 960W Current – Output (Max): 40A Approvals: CE, cULus, EAC, TUV Voltage – Input: 320 ~ 575 VAC, 450 ~ 800 VDC Operating Temperature: -25°C ~ 70°C Type: Enclosed Manufacturer: Weidmuller

This ismanufactured by Weidmuller. The manufacturer part number is 1469560000. Additionally, the product is supplied with 1 outputs. Carries 500000h. Features a 24v dc output voltage. While its minimum temperature is -25°c. It has a/an dc output voltage . Feature 960w of power rating. Its input voltage is 320 → 575v ac. It has typical 16 weeks of manufacturer standard lead time. It features enclosed ac dc converter 1 output 24v 40a 320 ~ 575 vac, 450 ~ 800 vdc input. 3kv of isolation voltage. The splendid features of the product include adjustable output, ip20. The product is available in din rail configuration. The product is widely employed in industrial, ite (commercial). The product pro eco3 (960w), is a highly preferred choice for users. It has a 24v output voltage. The product’s diameters include 6.30″ l x 4.72″ w x 4.92″ h (160.0mm x 120.0mm x 125.0mm). It is a highly efficient product with an 90% of high efficiency. The product features power and watts of 960w. The maximum product’s output current is 40a. The product complies with ce, culus, eac, tuv. The possible product’s input voltage is 320 ~ 575 vac, 450 ~ 800 vdc. The product has -25°c ~ 70°c operating temperature range. It comes in enclosed configuration. The weidmuller’s product offers user-desired applications.
